CS1614E

40cm CHAINSAW (KIT)

Read the full description below

  • Bar length (cm) 40cm Bar Length
  • Chain speed 20 M/S Chain Speed
Share this product
Find a Stockist

Product Specification

Voltage (V)56
Chain Speed (m/s)20
Sproket6 Teeth
IP ClassIPX4
Chain Drive Links56
Sound Pressure Level Lpa (dB(A))91
Sound Power Level Lwa (dB(A))102
Vibration (M/S²)3.37/2.82
Oil Feeding TypeAuto
Oil Level Indicator TypeOil Window
Varible Speed ControlYes
Bar Length (cm)40
Chain / Bar Gauge (mm)1.1
Chain / Bar Pitch (mm)9.5
File Size (mm)4
Oil Tank Capacity(ml)150
Tool Length (mm)803
Tool Width (mm)252
Tool Height (mm)203
Battery PortSingle Port
Chain Brake1
Show all

Full Product Description

Say hello to the CS1611E 40cm chainsaw kit. The CS1610E chainsaw is built to be put through its paces. Cut through logs up to 40cm in width like butter and stay in control with bumper spikes to keep you moving in the right direction – the 20 m/s chain speed will take care of the rest.
Before you get going, ensure you engage the chain brake so you can work in the safest of conditions. If you do experience kickback, the powerful brake will bring the chain to a halt, minimising risk to the user.
The 5.0Ah battery which is provided in this chainsaw kit will allow you to make up to 300 cuts on a single charge – this should give you ample time to complete your tasks, but if not, enjoy a break while the battery fully recharges in 40 minutes.
The oil reservoir is 150ml and is easy to monitor how much oil is left in the tank by looking through the opaque oil inspection window. The chainsaw is automatically lubricated from this tank, so all you need to do is keep check on the oil levels.
When you have finished cutting, first remove the battery to ensure that you do not accidentally press the trigger to start the chain, then safely store away in our durable chainsaw bag (BCS1000), which is available to purchase separately.

Benefits of EGO Power+ Technology

  • Battery power and compatibility
    Delivering the power you need, for every job. Our 56V ARC Lithium™ battery is a marvel of engineering that surpasses the competition on every level, and have the capability to out perform petrol. All our 56V ARC Lithium™ batteries are interchangeable across the entire EGO cordless range - so there’s a battery for every tool and every job.
  • Durability and Performance
    As a mature, market-leading company and part of the Chervon Group, we pride ourselves on best practices that ensure our products are of the highest possible standard. In fact, we’re so confident in the quality and performance of our tools that we offer industry-leading warranties for tools and batteries purchased by professional and domestic users.
  • Eco friendliness
    At EGO, we think beyond performance. Our experts are relentless in their drive to innovate tools for a better world. EGO’s 56V ARC Lithium™ batteries not only outperform fuel, they are better for the environment. Help us lead Europe to a battery powered future and commit to the smarter, greener way of working outdoors.

BATTERY FEATURES

  • A BATTERY LIKE NO OTHER
    Designed to maximise performance
    01 / 05
    Next
  • Exterior Mounted Battery
    Stays cool to deliver longer lasting power
    02 / 05
    Next
  • Power Management System
    Ensures the very best power, performance and run time
    03 / 05
    Next
  • Unique 'Keep Cool'™ Technology
    Maintains performance by preventing overheating
    04 / 05
    Next
  • Innovative Arc-Shaped Design
    Lowers temperature across the battery
    05 / 05
    Start
